Private beta — Lighting

Draw less.
Design more.

Professional extensions for SketchUp®, built for architects and interior designers who are tired of redrawing the same thing twice.

Join the beta Explore Lighting
AAAAAAABB SS3S3 B: CENTER ON ISLAND4'-0" O.C. KITCHEN101 10'-0"4'-0"4'-0"4'-0"2'-0"24'-0"6'-0"6'-0"6'-0"6'-0"2'-6"6'-3"5'-9"3'-6"18'-0" N 02'4'8'
A — RECESSED DOWNLIGHT B — PENDANT S / S3— SINGLE-POLE / 3-WAY SWITCH SWITCH LEG
1
LIGHTING & SWITCHING PLAN — KITCHEN 101
SCALE: 1/4" = 1'-0"
E-101
S1 → S3 · auto 3-way
Fixture schedule
7 × TYPE A · 2 × TYPE B · REV C
01 / The suite

One toolkit for every drawing you dread.

Each tool solves one bottleneck between design and documentation. One license, one look, one update channel.

Beta
Lighting
Fixture runs, swags that follow, automatic 3-way switching and schedules straight to LayOut.
Preview
Tile
Real tile layouts on any face: patterns, grout joints, offsets and cut counts.
Interactive demo
Stone Planner
Layout slabs, seams, overhangs and edge profiles with material and cut estimates.
In development
Cladding
Siding, panels and board-and-batten as real geometry, wrapped around corners and openings.
In development
Dimension
Automatic, clean dimension strings on plans and elevations that update with the model.
In development
Array
Custom arrays along paths, grids and curves, with live spacing and count control.
In development
Morph
Sculpt and morph forms with precision. Organic shapes without leaving your workflow.
In development
Landscape
Plants, hardscape and irrigation layouts with species data and spacing counts.
In development
Glass Shower Doors
Configurable glass enclosures: panel sizes, hardware, hinges and seals.
In development
Control Joints
Place and schedule control joints on slabs and walls with spacing and pattern rules.
In development
Pools
Design pools, spas and water features with depths, tiling, steps and equipment.
02 / First release — Lighting

Lighting plans that update themselves.

01
Place a run in two clicks
Set count or exact spacing, with setbacks.
02
Swags follow every move
Control relationships re-route on their own.
03
Switching that knows the code
S1 becomes S3, a third becomes S4.
04
One click to LayOut + PDF
Plans, fixture, control and button schedules.
Explore Lighting
SHEET 02 / 06REV C
Fixture schedule
EL-001Recessed 2" round · 850 lm3000KEL-002Recessed 2" round · 850 lm3000KEL-003Recessed 2" round · 850 lm3000K
SHEET 03 / 06REV C
Control schedule
SHEET 04 / 06REV C
Button assignments
03 / Why DORN

Built by a designer-builder.

Hello, I'm a California contractor drawn to the freedom of designing and building. I come from the trades, and over the years I've worked to make my own process more efficient.

Now I'm sharing the extensions I built along the way, in the hope that they make your process a little less tedious and a lot more enjoyable.

— DORN

04 / Pricing

The price grows with the suite.
Your rate stays locked.

Every plan includes each new tool the day it ships. As the suite grows, the price for new customers rises. Your rate stays locked.

Individual
$149 / year
or $19 / month
Lighting, plus each new tool as it ships2 machine activationsAll updates included
Notify me at launch
Studio
$199 / seat / year
3-seat minimum
Everything in IndividualShared product library across the teamSeat management and invoicing
Talk to us
Subscriptions renew automatically at the then-current price for your plan until you cancel. Cancel anytime online; access continues to the end of the paid period. Full refund within 14 days of your first purchase. Prices exclude applicable tax. Orders are processed by Paddle, our reseller and merchant of record. See subscription terms.
Private beta

Get early access.

A small private beta for architects and interior designers. Invites go out in waves, with early-access pricing for beta participants.

By requesting an invite you agree to receive beta and product emails from DORN. Unsubscribe anytime. See our Privacy Policy.
